Hook Type Shot Blasting Machine, Improve Fatigue Strength
Key Specifications / Features
Model No.: JX-HTS-02 Hits: 104
Hook Type Shot Blasting Machine Manufacturer JX Offers Hook Type Shot Blasting Machine, Multiple Sizes, Fatigue Strength, High-efficient Blast Wheels.
Request a quoteTags:
Detail Infomation
Characteristics
1. Hook Type Shot Blasting Machine is a kind of high efficiency shot blasting machine with non-pit.
2. Large inner available cleaning space, compacted structure and scientific design, can be designed and manufactured according to the order.
3. No special request for the work piece structure, can be used for different kind of work pieces.
4. Widely used in cleaning and strengthen for Fragile or Irregularly Shaped Parts, Medium-sized or Large Parts, Die Cast Parts, Sand Removal and External Finishing.
Description
Hook Type Shot Blasting Machine is design to handle mix load of medium & large components including fragile & irregular shapes. Small components can also be cleaned by loading into carrier basket. Various work handing schemes like straight, tee, y and continuous loop is possible. It can handle load upto 5000 kg/hanger or more.
Application
Hook Type Shot Blasting Machine are used for desanding and decoring of pieces. small, medium and very large parts can be economically cleaned.
Details
1. Main blast cabinet with inspection door.
2. Blast wheel units with drive mechanism.
3. Abrasive circulation unit.
4. Bucket elevator unit.
5. Abrasive separation/cleaning system with storage hopper.
6. Dust collector with cleaning mechanism.
7. Roller conveyor system at inlet & outlet side.
8. Control panel with PLC control system.
Technical Parameters
1. Hook Type Shot Blasting Machine is a kind of high efficiency shot blasting machine with non-pit.
2. Large inner available cleaning space, compacted structure and scientific design, can be designed and manufactured according to the order.
3. No special request for the work piece structure, can be used for different kind of work pieces.
4. Widely used in cleaning and strengthen for Fragile or Irregularly Shaped Parts, Medium-sized or Large Parts, Die Cast Parts, Sand Removal and External Finishing.
Description
Hook Type Shot Blasting Machine is design to handle mix load of medium & large components including fragile & irregular shapes. Small components can also be cleaned by loading into carrier basket. Various work handing schemes like straight, tee, y and continuous loop is possible. It can handle load upto 5000 kg/hanger or more.
Application
Hook Type Shot Blasting Machine are used for desanding and decoring of pieces. small, medium and very large parts can be economically cleaned.
Details
1. Main blast cabinet with inspection door.
2. Blast wheel units with drive mechanism.
3. Abrasive circulation unit.
4. Bucket elevator unit.
5. Abrasive separation/cleaning system with storage hopper.
6. Dust collector with cleaning mechanism.
7. Roller conveyor system at inlet & outlet side.
8. Control panel with PLC control system.
Technical Parameters
| Hook Type Shot Blasting Machines | |||||||||
| Item | Unit | DX376 | DX378B | DX378C | DX3710 | DX3720 | DX3730 | DX3750 | DX37100 |
| Max. weight of cleaning | kg | 500 | 600 | 800 | 1000 | 2000 | 3000 | 5000 | 10000 |
| Abrasive flow rate | kg/min | 2*200 | 2*200 | 2*250 | 2*250 | 3*250 | 3*250 | 4*250 | 4*250 |
| Ventilation capacity | m3/h | 5000 | 5000 | 5000 | 5000 | 9000 | 11000 | 14000 | 16000 |
| Lifting amount of elevating conveyor | t/h | 24 | 24 | 30 | 30 | 45 | 45 | 60 | 75 |
| Separating amount of separator | t/h | 24 | 24 | 30 | 30 | 45 | 45 | 60 | 75 |
| Max overall dimensions of suspender | mm | Ø600*1200 | Ø700*1200 | Ø1000*1600 | Ø1200*1800 | Ø1400*2200 | Ø1600*2300 | Ø1800*2500 | Ø3000*3000 |
